Merits P326E0M Vision Sport Mid-Wheel Drive Power Wheelchair


(Model No. P326E0M)

Starting at: $2,867.00 USD

Key Features

    • Two-Tone Seat with Semi-Reclining Back
    • Solid Caster & Foam Filled Drive Wheels
    • Standard Swing Back Joystick Mount
    • 10" Drive Tires & 20" Captain Seat
Secure Checkout 256-bit SSL encryption on every order
Free Shipping On all orders over $50 across the USA
Price Match Guarantee Found it cheaper? We'll match it
Easy Returns Hassle-free returns within 30 days
Weight Capacity 300 lbs.
Battery Range Up to 18 miles
Turning Radius 20"
Top Speed Up to 4 mph

Merits


(Model No. P326E0M)

Starting at: $2,867.00 USD
Regular price $2,867.00
Shipping calculated at checkout.
Lead Time: This product ships in 2-7 business days.

Description
Specifications
Information

Merits P326E0M Vision Sport Mid-Wheel-Drive Power Wheelchair

The Vision Sport P326E0M uses a mid-wheel-drive layout with full suspension and a front-caster obstacle-climb design. With the drive wheels centered beneath the chair, the powerbase is intended to maneuver in tighter spaces than a conventional rear-drive layout. The suspension and caster design are relevant when routes include ordinary floor transitions, but they do not make every curb, threshold or outdoor surface suitable; stay within the chair's operating guidance and assess the actual route.

Seat and Control Setup

The listing describes a semi-reclining back, height-adjustable two-tone seat, and armrests adjustable for height and width. Captain or pan seating and left- or right-side joystick placement are selected during configuration; elevating legrests and an armrest bag are optional upgrades. These choices change how the user sits, approaches a table, supports the legs and reaches the controller. Confirm the chosen seat, control side and legrest arrangement with the user's measurements and transfer routine before placing the order.

Driving and Controls

A programmable Dynamic LiNX controller lets a qualified provider adjust drive programming to the user's needs. The standard swing-back joystick mount can move away for side access and transfers, but users and caregivers should follow the instructions when repositioning it. The chair's mid-wheel design can feel different when turning in confined spaces or crossing uneven transitions; allow time to learn its response in a clear, familiar area before using it in busy rooms or unfamiliar routes.

Range, Capacity and Charging

The retailer lists a 300 lb weight capacity, up to 18 miles of range, a top speed of up to 4 mph and a 20 inch turning radius for the P326E0M listing. Range varies with occupant and cargo weight, terrain, temperature, battery condition, tire pressure and driving style. The supplied off-board 4 amp charger supports charging away from the chair; use the manufacturer's battery and charging instructions and plan charging around the expected trips rather than treating the listed range as guaranteed.

Fit and Transport

Measure doorways, turning areas and the vehicle's loading space against the complete selected chair. Verify seating width, joystick side, legrest choice and overall dimensions with the current P326E0M order configuration; figures for another Vision Sport suffix may not describe this chair. Before regular use, ensure that the user can reach and operate the controller and that the seating supports the intended posture. This powered chair is a complete mobility base, not a folding travel chair.

Max Speed 5mph
Range up to 18 miles
Turning Radius 20'
Ground Clearance 2'
Motor DC 24V, 160W
Controller Dynamic LiNX
Battery 12V/U1 x 2pcs
Charger 4A off-board
Gradient 6°
Casters 6' front and rear solid tires
Drive Wheels 10' solid tires
Brakes intelligent, regenerative, electromagnetic
Seat Width 19'
Seat Depth 18'
Seat Height 21.5' - 23.5'
Backrest Height 20'
Overall Length 34'
Overall Height 48.5'
Overall Width 24'
Total Weight 184 lbs.
Weight Capacity 300 lbs.
Ownership Information:
Warranty Information:

Lifetime Warranty: Power Chair Frame

One Year Limited Warranty: Electronic Controller - Drive Train Components

Six Month Limited Warranty: Plastic Parts, Rubber Parts, Bearings (Excluding plastic shroud)

Shipping / Returns Information:
This unit is delivered via common LTL carrier on a pallet. This will be left curbside for standard delivery. Some carriers schedule delivery appointments.

The following conditions apply:
  • This item has a 20% Restocking Fee.
  • You are responsible for the cost of return shipping.
  • The product must be new and unused and in the original packaging.
  • All accessories and items that were included in the box must be returned.
  • Items canceled after the product has already shipped will be considered a return.
  • Delivery and service fees are not refundable.
  • Custom-made by the manufacturer to suit your specific needs are non-returnable.
  • An RA (Return Authorization) from Top Mobility must be requested within 15 days of delivery.
  • The item must be shipped back to the address noted on the RA within 15 days.
  • Once approved, your refund, minus any restocking and freight fees, will be issued to your original form of payment.

  • If you have questions about this item please call a Top Mobility Customer Service Expert at 1-888-364-3813.
