EZ-ACCESS SUITCASE Trifold AS Portable Ramp

The SUITCASE Trifold AS is a portable aluminum ramp that folds into two carryable sections. A slip-resistant surface, interlocking hinge and self-adjusting bottom transition plate are designed to support setup across suitable surfaces. The retailer lists 6-, 7-, 8- and 10-foot lengths at 29.5 inches wide. The right length depends on the rise, available run, landing space and the ramp slope appropriate for the user and mobility device.

Select Length and Check Slope

Measure the vertical rise and the clear space available at both ends before choosing a length. Consult EZ-ACCESS's slope and load guidance for the exact configuration and intended use; do not assume that any listed length is suitable for every rise or every wheelchair or scooter. Longer ramps require more approach and landing space, and a ramp placed at too steep an angle can be difficult to navigate.

Folding, Section Weight and Transitions

The ramp separates into two sections for carrying and folds at an interlocking hinge. Section weight rises with length: the listing gives approximately 19 lb per section for 6 feet, 22 lb for 7 feet, 25 lb for 8 feet and 30 lb for 10 feet. Plan how each section will be carried, unfolded, aligned and secured. The self-adjusting bottom plate helps meet ground surfaces, while the top transition must sit securely at the landing. Keep fingers clear of the hinge and confirm both sections are fully positioned before use.

Top-Lip Option and Placement

A top-lip extension is a separate add-on, not automatically included. Confirm whether it is needed to engage the landing and whether it is compatible with the selected ramp length and use. Check the doorway, threshold and landing surfaces so the ramp sits securely at both ends without shifting.

Before Ordering and Use

Verify rise, available run, selected length, section weights, transition fit and the exact load/slope guidance for the configuration. Follow EZ-ACCESS's setup and inspection instructions and make sure the ramp is secured at both ends. The product listing does not establish one universal load or slope limit for every length and setup.
