Proactive Medical Products

Protekt All-in-One Portable Patient Folding Lift 350lb Weight Capacity


(Model No. PAM-33350)

Starting at: $1,299.00 USD

Key Features

    • Folding full-body lift: The powered lift folds for storage and transportation, helping households with limited space put the equipment away between assessed sling-transfer routines.
    • Battery and control monitoring: Battery-powered lifting, a battery gauge, and warning alarms help the caregiver monitor operation, while the emergency-stop control provides a dedicated way to halt powered movement.
CONFIGURE
Secure Checkout 256-bit SSL encryption on every order
Free Shipping On all orders over $50 across the USA
Price Match Guarantee Found it cheaper? We'll match it
Easy Returns Hassle-free returns within 30 days

Proactive Medical Products


(Model No. PAM-33350)

Starting at: $1,299.00 USD
$1,299.00
Shipping calculated at checkout.
This product usually ships in 2-4 business days.

Description
Specifications
Information

Protekt All-In-One 33350 Portable Electric Patient Lift

The Protekt All-In-One 33350 is a foldable electric lift for transferring a dependent user between a bed, chair, commode or vehicle. Proactive rates it for a maximum safe working load of 350 lb and lists a lifting range from 22.2 to 64.7 in. The 4-point spreader bar is designed for clip-style slings only; sling capacity must be at least as high as the user's weight.

Power and transport setup

The model 33350 uses a 24V, 5Ah battery pack and a DC charger. Its manual describes the battery pack as optional and the charging cradle as an option; confirm the battery, charger, sling and other package contents with Top Mobility before ordering. The lift weighs 94.2 lb and folds for storage or vehicle transport. Its manual lists 25 full-load lift cycles per charge; actual performance depends on battery condition and load.

Transfer safety and fit

This device is for transferring a user between surfaces, not for transporting a person from place to place while in the sling. Use it on a flat, dry surface, keep the base wide during lifting and never leave the user unattended. Proactive advises that an experienced caregiver or medical attendant guide initial transfers; practice the operation and follow the owner's manual and care plan. Check base clearance, turning room and lift height against the bed, chair or vehicle before use.

Model33350
Maximum safe working load350 lb (159 kg)
Unit weight unloaded94.2 lb (42.8 kg)
Lifting height range22.2-64.7 in (564-1643 mm)
Base length41.0 in (1041 mm)
Base width, closed25.6 in (650 mm)
Base width, open32.0 in (813 mm)
Turning diameter, base open55.7 in (1414 mm)
Turning diameter, base closed51.2 in (1300 mm)
Battery24V DC, 5Ah; battery pack optional per manual
Lift cycles per charge25 full-load cycles
Duty cycleMaximum 2 minutes on / 18 minutes off
Sling connectionClip-style slings only
Ownership Information:
Owner's Manual
Brochure
Sling Reference Guide
Sling Sizing Guide
Warranty Information:

Warranty

Electronics: 2-YearFrame: 3-YearBattery: 1-Year
