EV Rider

MiniRider Lite

4 Wheel Travel Mobility Scooter
(Model No. EV-WT-4DKC)
Colors:

Starting at: $1,155.00 USD

Key Features

    • Tool-Free Disassembly: Breaks down easily into four separate pieces to fit inside most standard vehicle trunks.
    • Lightweight Components: The total weight is 92 lbs with batteries, but the heaviest piece is only 35 lbs (front section), making it easy to lift.
Secure Checkout 256-bit SSL encryption on every order
Free Shipping On all orders over $50 across the USA
Price Match Guarantee Found it cheaper? We'll match it
Easy Returns Hassle-free returns within 30 days
Weight Capacity 280 lbs.
Battery Range Up to 18 miles
Turning Radius 52"
Top Speed Up to 4 mph
Unit Weight 93 lbs.

EV Rider

4 Wheel Travel Mobility Scooter
(Model No. EV-WT-4DKC)

Starting at: $1,155.00 USD
Regular price $1,155.00
Shipping calculated at checkout.

Configure Your MiniRider Lite

Color✱ Selection Required
Battery Size✱ Selection Required
Product Accessories
Starting from: $1,155.00

Free shipping on this order!

Description
Specifications
Information

The EV Rider MiniRider Lite takes a different approach to portability from a one-piece folding scooter: it separates into a seat, battery pack, front section, and rear section. That can make car loading more manageable for someone who cannot lift a complete scooter but can handle several smaller components. Its padded swivel seat and armrests also give it a more conventional seated arrangement than the smallest folders. The trade-off is an assembly routine at each destination.

Four Pieces Instead of One Heavy Package

The manufacturer's manual puts the heaviest front section at approximately 35 lbs, the seat at about 16 lbs, and the battery pack at about 20 lbs. Those component weights are more useful for transport planning than assuming that the word Lite means the complete scooter can be carried easily. Each piece still needs to be lifted over the vehicle's loading edge and placed where it will not shift during travel.

Disassembly is tool-free and includes removing the seat and battery pack, lowering the tiller, and separating the chassis sections. It is not remote folding. Allow space beside the vehicle to work, keep the scooter switched off, and follow the connection sequence when reassembling. Check that the sections and seat lock correctly before use. Multiple manageable lifts can be preferable to one large lift, but they involve more bending and handling.

Conventional Seating in a Travel Frame

The MiniRider Lite is 42.5 inches long and 19 inches wide. Its 17-inch-wide, 16-inch-deep seat offers a different fit from shallow folding seats, while the swivel function helps position the rider for boarding and getting up. Flip-up, width-adjustable armrests and an angle-adjustable tiller allow the seated space and control reach to be tailored. Make adjustments while stationary and turn the power off before transferring.

The published turning radius is 52 inches. Its relatively narrow width helps with straight door approaches, but a corner requires more space than the smallest folding scooters. Measure the actual turn from a hallway into a room rather than judging indoor suitability from width alone. Return the swivel seat to the forward position and ensure it is locked before driving; a rotating seat is a transfer aid, not a driving position.

Everyday Controls and Brake Operation

The console combines key operation, a speed dial, battery indication, and lever controls for forward and reverse travel. The maximum speed is up to 4 mph. A low setting makes it easier to learn the throttle response and steer around people or furniture. Releasing the lever activates the electromagnetic brake, so normal stopping follows the throttle returning to neutral rather than a separate manual braking routine.

The freewheel lever allows an attendant to push the scooter when the motor is disengaged. That is for controlled repositioning on level ground, not occupied downhill travel. Always return it to drive mode before use. Check the battery indication and the condition of the tires before setting off, and do not ignore erratic movement or unusual control response. A scooter that starts successfully still needs its seating and chassis connections checked after transport.

Standard Batteries Versus the Longer-Range Option

The standard setup uses sealed lead-acid batteries with a 12Ah rating; an 18Ah configuration is optional. EV Rider publishes up to 10 miles with the standard setup and up to 18 miles with the larger option. The longer figure belongs to that different battery configuration, not to every MiniRider Lite. Consider the handling implications of the selected pack as well as the extra potential distance when comparing the options.

Both ranges describe favorable test conditions. Rider and carried weight, starts and stops, slopes, temperature, and battery wear can shorten actual distance. Use a reserve for the return leg, charge with the approved equipment, and keep the charging area dry and ventilated. The removable pack allows the charging task to be arranged separately from the whole chassis. For commercial transport, confirm the carrier's requirements for the exact batteries rather than assuming universal acceptance.

Surface Limits and the Best Reason to Choose It

The solid PU tires avoid punctures, but small wheels do not make the scooter appropriate for rough trails or curb climbing. The owner manual's intended-use notice specifies indoor use and a maximum safe slope of 3 degrees. It also excludes use as a seat in a moving motor vehicle. Those instructions take priority when planning a route; portability between destinations does not establish unrestricted outdoor capability.

A front basket is part of the model's illustrated assembly, while the larger battery is an optional configuration and should not be assumed included. Keep carried items secure and avoid adding loads that interfere with steering. The MiniRider Lite is most compelling when a swivel seat, armrests, and several smaller transport lifts solve practical needs. It is less compelling when the buyer wants instant remote folding or cannot comfortably manage repeated assembly and battery handling.

Length 42.5″
Width 19″
Height 36″
Front section 35 lbs
Rear section 26 lbs
Battery pack 20 lbs
Seat 16 lbs
Weight with batteries 92 lbs
without battery 72 lbs
Battery 12 AH (option 18AH)
Charger 2A Off-Board
Tire Size 8″ x 2″
Front Tire 200X50 PU TIRE
Rear tire 200X50 PU TIRE
Ground clearance 3″
Seat height 23″
Seat height – cushion to deck 20″
Seat Fish on seat
Seat width 17″
Seat depth 16″
Top Speed 4 mph
Battery range 12V 12AH SLA Battery Up to 10 miles
Battery range 12V 18AH SLA Battery Up to 18 miles
Turning radius 52″
Wheelbase 31″
Climbing angle 8 degrees
Motor size 270 Watts
Max. user weight 280 lbs
Controller Curtis 45A
Colors Red, Green, Silver, Blue
Ownership Information:
Warranty Information:

Frame: 3 Years

Drive Train: 1 Year

Electronics: 1 Year

Batteries: N/A*
